DTS3

Direct to Substrate LED UV Ink


artisink-logo

DTS Ink Science

  • Drying inks through polymerization utilizing UV curing technology
  • UV LED curing improved by enabling the usage of thinner and heat-sensitive substrates
  • FOIF (flash on ink firing) technology allows the UV LEDs to efficiently utilize the input power
  • FOIF turns on and off the LEDs instantly in sync with ink firing
  • As a result, FOIF lowers the operating costs and maximize the longevity of the printhead.
  • The wavelength for the DTS LED UV curable ink is ±395nm


High-Density White

  • Printing on transparent or dark materials requires the usage of white ink layering which serves as an undercoat
  • DTS UV LED white ink offers high-density white which enables rich and vibrant colors on transparent and dark substrates


Artistic Varnish

  • Once CMYK graphics are printed, varnish ink can be layered to create a 3D finish.
  • Multiple layers can be applied for dramatic effects.




Main Features

  • High color density
  • Wide color gamut
  • Instant drying
  • Excellent adhesion to both coated and uncoated media
  • VOC free and environmental friendly
  • Superior scratch and alcohol resistance
  • 3 years outdoor durability

Colors

Cyan
Magenta
Yellow
Black
Lt Cyan
Lt Magenta
White
Varnish

Applications

The DTS3 LED UV inks are developed to offer an excellent adhesion and scratch resistance.
Suitable for Leather, Timber, Glass, Tiles, Metals, Wood, Density boards, Plastic boards to Aluminum.




Ordering Information

Product No. Description Ink Compatibility

DTS3 - 1000-001 Cyan UV-LED Ink DTS3, 1000ml artis 3000U, artis 5000U
DTS3 - 1000-002 Magenta UV-LED Ink DTS3, 1000ml artis 3000U, artis 5000U
DTS3 - 1000-003 Yellow UV-LED Ink DTS3, 1000ml artis 3000U, artis 5000U
DTS3 - 1000-004 Black UV-LED Ink DTS3, 1000ml artis 3000U, artis 5000U
DTS3 - 1000-005 Light Cyan UV-LED Ink DTS3, 1000ml artis 3000U, artis 5000U
DTS3 - 1000-006 Light Magenta UV-LED Ink DTS3, 1000ml artis 3000U, artis 5000U
DTS3 - 1000-007 White UV-LED Ink DTS3, 1000ml artis 3000U, artis 5000U
DTS3 - 1000-008 Varnish UV-LED Ink DTS3, 1000ml artis 3000U, artis 5000U
DTS3 - 500-001 Cyan UV-LED Ink DTS3, 500ml artis 3000U, artis 5000U
DTS3 - 500-002 Magenta UV-LED Ink DTS3, 500ml artis 3000U, artis 5000U
DTS3 - 500-003 Yellow UV-LED Ink DTS3, 500ml artis 3000U, artis 5000U
DTS3 - 500-004 Black UV-LED Ink DTS3, 500ml artis 3000U, artis 5000U
DTS3 - 500-005 Light Cyan UV-LED Ink DTS3, 500ml artis 3000U, artis 5000U
DTS3 - 500-006 Light Magenta UV-LED Ink DTS3, 500ml artis 3000U, artis 5000U
DTS3 - 500-007 White UV-LED Ink DTS3, 500ml artis 3000U, artis 5000U
DTS3 - 500-008 Varnish UV-LED Ink DTS3, 500ml artis 3000U, artis 5000U
DTS3 - 200-001 Cyan UV-LED Ink DTS3, 200ml artis 3000U, artis 5000U
DTS3 - 200-002 Magenta UV-LED Ink DTS3, 200ml artis 3000U, artis 5000U
DTS3 - 200-003 Yellow UV-LED Ink DTS3, 200ml artis 3000U, artis 5000U
DTS3 - 200-004 Black UV-LED Ink DTS3, 200ml artis 3000U, artis 5000U
DTS3 - 200-005 Light Cyan UV-LED Ink DTS3, 200ml artis 3000U, artis 5000U
DTS3 - 200-006 Light Magenta UV-LED Ink DTS3, 200ml artis 3000U, artis 5000U
DTS3 - 200-007 White UV-LED Ink DTS3, 200ml artis 3000U, artis 5000U
DTS3 - 200-008 Varnish UV-LED Ink DTS3, 200ml artis 3000U, artis 5000U

Cleaning agent Description
BRCA-U-1000-001 Cleaning agent for LED UV inks, 1000 ml
BRCA-U-500-001 Cleaning agent for LED UV inks, 500 ml
BRCA-U-200-001 Cleaning agent for LED UV inks, 200 ml

Fixing agent Description
BRCA-U-1000-001 Fixing agent for LED UV inks, 1000 ml
BRCA-U-500-001 Fixing agent for LED UV inks, 500 ml
BRCA-U-200-001 Fixing agent for LED UV inks, 200 ml



left-leaf

ECO

right-leaf

Go green with artisJet’s DTS3 UV inks. Print toxin free and virtually odorless. DTS3 UV inks are environmentally friendly. UV inks are cured and fixed to the substrate when being activated with UV light. The curing process hardens the ink, without any evaporation. Ideal for general industrial use, restaurants, hotels, hospitals and indoor signage application.
